Comelit Logos WiFi Monitor LS8741 SB2

Comelit LS8741 Logos Wi-Fi Hands-Free Monitor for Simplebus 2

The Comelit LS8741 is a 5-inch hands-free Wi-Fi colour door entry monitor designed for the Simplebus 2 system.

It integrates with the free Comelit App for remote call answering via smartphone or tablet, and supports voice assistants including Amazon Alexa, Google Assistant and Echo Show.

NOTES

If you have an existing Simplebus 2 colour system ( using 4888c or 1210 ) you could replace the existing monitors with LS8731 or LS8701.They will not work on a black and white system using 4888.

If you are adding LS8741 wifi monitors to an existing system using 4888c then the 4888C needs to be above version 053 to be able to support LS8741 monitors.

You can find the version of the 4888c by opening the little door on the front of the 4888c, there is a sticker on the inside, if you email us a photo we can tell if it is above version 053.

There are rules about how many LS8741 wifi monitors you can have on a system, and that number depends on the type of PSU powering the system, the type of existing monitors and the total number of existing monitors on the system. This is because the LS8741 monitor takes more power from the bus that non wifi monitors.

Features

5-inch 16:9 colour TFT display

Built-in Wi-Fi (2.4Ghz) with Comelit App integration for remote call answering

Compatible with Alexa, Google Assistant and Echo Show

Video memory storing up to 8 recordings

Backplate with 1214/2C distribution terminal included

Specifications

System: Simplebus 2

Display: 5-inch TFT 16:9

Hands-free full-duplex

Wi-Fi: IEEE 802.11 b/g/n, 2.4 GHz

Voltage: 33 VDC (bus powered)

Dimensions: 135 x 170 x 23mm (L x H x D)

Weight: 430g

Mounting: Surface-mounted with metal backplate

Max Secondary Monitors per Apartment: 3 (LS8731/LS8701)
